Model

With/Without eye tracker

Screen

15.0″, Aspect ratio: 4:3, LED Backlit

Screen Resolution

1024 x 768 pixels (XGA)

Touch Panel

Projected Capacitive Touch with Gorilla® Glass, 10 point multi touch

Dimensions

36,9 x 32,6 x 11,2 cm
14.5 x 12.8 x 4.4 inches

Weight

3,8 kg
8.4 lbs

Speakers

2 x 3 W Closed Box Speakers

Microphone

1 x Analog Microphone

Processor

Intel® Celeron Quad Core Processor J1900 (2M Cache, 2 Ghz)

RAM

4 GB DDR3

Operating System

Microsoft Windows 8.1 and Windows 10

Hard disk drive

2.5″ SSD 256 GB

SD-Card

MicroSD-Card 32 GB

Connectors

1 x Connector for an HDMI 1.3 Connector Type A cable
2 x USB 2.0
1 x USB 3.0
1 x RJ45 100/1000 Mbit/s (Ethernet)
2 x 3.5 Switch connector interface
1 x 3.5 mm Headphone jack (stereo) with jack detection
1 x 24 VDC 2.5/5.5 mm (power connector)

Buttons

1 x Power On
1 x Volume Up
1 x Volume Down
1 x Menu
2 x Programmable

WLAN (optional)

IEEE802.11 b/g/n Dual antenna diversity system

Bluetooth® (optional)

Bluetooth® 3.0+HS

IR Remote Control (Environmental Control Unit)

GEWA Programmable IR Remote Control (ECU)

Cameras

Forward facing Camera 5 MP auto focus
Camera facing user 2 MP fixed focus

Eye Tracker

When included, the Tobii IS4 Module is used

Battery Run Time

~ 8/9.5h

Battery Charge Time

Maximum 5.4 h (0-100%)

Battery Storage Time

Maximum 6 months @ 40-60 % charge

Deskstand

Integrated

Mounting System Supported

Tobii Dynavox QR adapter plate for Daessy and REHAdapt

Power Supply

Input: Universal 100 ~ 240 VAC / 50 ~ 60 Hz
Output: +24VDC / 0~2.71A

IP class

IP43 (with I/O covers in place)

Mobile Phone Compatability

Read our FAQ’s to see which mobile phones the Tobii Dynavox I-Series+ supports

Medical Classification

93/42/EEC (MDD) – Medical Device Directive, as amended by 2007/47/EC
